Streamline Hose Management with the Dixon Modular Connection System (MCS)

In industries where hydraulic systems power essential equipment, connecting multiple lines quickly and reliably can be a daily challenge. From construction machinery to steel production environments, downtime and misconnection issues cost businesses valuable time and money. The Dixon Modular Connection System (MCS) was engineered to solve exactly that.

What is the Modular Connection System (MCS)?

The MCS is an innovative connection platform designed to connect multiple couplings at once. Instead of attaching each line individually, operators can insert and lock an entire bundle of hydraulic connections in one motion.

The single system holds up to 10 hydraulic quick couplings, depending on the size and configuration. Compatible coupling sizes include 3/8”, 1/2”, 3/4”, and 1”, giving users flexibility to tailor their setup to specific equipment requirements.

Built with heavy-duty industrial performance in mind, the MCS reduces the risk of crossed or incorrect hose connections and simplifies maintenance, which are two of the most common challenges in hydraulic system management.

Benefits of MCS

One of the strengths of the MCS is the patented modular design, which allows blocks to be rearranged or customized based on application demands. Whether replacing alignment pins or swapping out fittings, the system is built for long-term adaptability.

The patented coupling retention system allows for simplified field repairs, and components can be serviced without the need to remove the full assembly. This helps reduce downtime and maintenance costs.

The cam-style latching mechanism provides a smooth connection, even when connecting under residual pressure, eliminating one of the most frustrating pain points faced by operators. All MCS working configurations are approved for 3,000 PSI working pressure, and certain configurations may be approved for working pressures up to 5,000 PSI. Contact Dixon to review specific applications.

Where is MCS Used?

The Dixon MCS supports a wide range of applications across multiple industries, including:

• Agriculture
• Automotive
• Demolition
• Die Casting
• Mobile Construction Equipment
• Oil & Gas
• Railroad
• Snow & Ice Removal
• Steel
• Forestry
• Mining

Wherever hydraulic systems need to be connected quickly, safely, and repeatedly, the MCS offers operators a fast and efficient solution.

MCS Success Story

A valued Dixon partner tested the MCS in the caster department of a steel mill, which is an environment where equipment is constantly exposed to heat, vibration, and rapid changeovers. Caster segments are regularly swapped out, and hydraulic assemblies often get mismatched during this process.

With the MCS, operators were able to eliminate crossed connections and reduce the time required for equipment changeouts. The single-motion attachment provided consistent, reliable connections every time.

After nine months of continued use, the couplers were inspected and showed no signs of wear or failure, reinforcing the durability and long-term dependability of the system.

Summary

The Dixon MCS delivers a smarter, faster way to manage multiple hydraulic connections across a wide range of industries. By consolidating up to 10 couplings into a single, easy-to-use unit, the MCS streamlines workflows, reduces errors, and minimizes downtime.

For operations that depend on consistent hydraulic connections, the MCS provides a reliable solution designed to improve efficiency and keep critical equipment running at its best.

Ready to harness the power of the MCS? Contact us online or call 877.963.4966.
